LL-NYRELZXTELL-NYRELZXTE
LED New York Compliant Recessed Edgelit Aluminum Exit Signs
Ultra bright, energy efficient, long life Red LEDs
UV-stabilized ultra-clear acrylic edgelit panel provides consistent, uniform illumination
Double face utilizes factory installed silver or white mylar background panel
New York City compliant 8” EXIT letters
UV-stabilized ultra-clear acrylic edgelit panel provides consistent, uniform illumination
Double face utilizes factory installed silver or white mylar background panel
New York City compliant 8” EXIT letters
Resources
Premium-grade, extruded aluminum housing
Extruded aluminum trim assembly is easily detachable providing accessibility for service or maintenance
Available in optional black or white powder-coated finishes
Self-adhesive Chevron appliques and guide template provided for directional indication
Extruded aluminum trim assembly is easily detachable providing accessibility for service or maintenance
Available in optional black or white powder-coated finishes
Self-adhesive Chevron appliques and guide template provided for directional indication
Dual 120V/277 voltage
Charge rate/power “ON” LED indicator light and push to-test switch for mandated code compliance testing
4.8V long life, maintenance-free, rechargeable NiCd battery (EM models only)
Internal solid-state transfer switch automatically connects the internal battery to LED board for minimum 90-minute emergency illumination
Fully automatic solid-state, two rate charger initiates battery charging to recharge a discharged battery in 24 hours
Charge rate/power “ON” LED indicator light and push to-test switch for mandated code compliance testing
4.8V long life, maintenance-free, rechargeable NiCd battery (EM models only)
Internal solid-state transfer switch automatically connects the internal battery to LED board for minimum 90-minute emergency illumination
Fully automatic solid-state, two rate charger initiates battery charging to recharge a discharged battery in 24 hours
Certified to CEC under Title 20 Regulations
Lumens
- 2021 Lm
Color / Finish
- Black
- White
Emergency Type
- Exit Signs
Lamp Source
- LED
Listings
- UL
Ratings & Compliance
- Damp
- NFPA 101
- NYC Compliant
- Title 20
Special Programs
- Quick Ship
Voltage
- 120 V
- 277 V
Warranty
- 7 yr
