LL-DLD
Screen Shot 2023-12-12 at 1.00.16 PM.png
LL-DLD-MS.JPEGLL-DLD
LED Downlight Disk
The LITELUME™ LED Downlight Disk (LL-DLD) luminaire can be used in a wide variety of indoor applications ( damp rated ) for new construction or retrofit. Featuring 5 CCT’s to choose from, and comes with and without PIR motion sensor. Applications include schools, hotels, office, commercial and residential use in 120v.
Resources
PF >.90
CRI 90
Dimmable : 120v Triac
CRI 90
Dimmable : 120v Triac
LEVITON: 6674,6633-P,6672, 6631,IPL06,1E1205,DB33K1,1F4205,1A2305,DD00R-DL,DSL06-1TW, IPV0R
LUTRON: NT-1000,S-603P,S-600P,DVCL-163P-WH,CTCL-153PDH-WH,SLV-600P-WH,DV-600P,CT-603PGH-WH,MIR-600THW-WH,MACL-153M-WH,S-600PR-WH,DVLV-603P-IV,DVW-603PGH-WH,DVFSQ-LFH,SCL-153PR-WH,CT-600PR-WH,CT-103PR-WH,DVWCL-153PH-LA,CTCL-150H-WH,CTCL-153PR-WH,STCL-153PH-WH
QuickShip Ordering Information
- LL-DLD-15W-5CCT-120-WH
- LL-DLD-15W-5CCT-120-WH-MS
Package: LL-DLD-15W-5CCT-120-WH
Packing size: 7.4x7.4x1.54inch
Weight: 0.88 LBS (1 pcs)
Packing size: 17.32x15.59x7.99inch
Weight: 17.64 LBS (20 pcs/ctn)
Pallet size: 42x48x70 inch
Qty：960 pcs/ 48 ctn
Total Weight: 900 LBS
Weight: 0.88 LBS (1 pcs)
Packing size: 17.32x15.59x7.99inch
Weight: 17.64 LBS (20 pcs/ctn)
Pallet size: 42x48x70 inch
Qty：960 pcs/ 48 ctn
Total Weight: 900 LBS
Package: LL-DLD-15W-5CCT-120-WH-MS
Packing size: 7.48x7.48x2.05inch
Weight: 1.1 LBS (1pcs)
Packing size: 21.26x15.75x8.07 inch
Weight: 22.04 LBS (20 pcs/carton)
Pallet size: 42x48x70 inch
Qty：960 pcs/ 48 ctn
Total Weight: 1088 LBS
Packing size: 7.48x7.48x2.05inch
Weight: 1.1 LBS (1pcs)
Packing size: 21.26x15.75x8.07 inch
Weight: 22.04 LBS (20 pcs/carton)
Pallet size: 42x48x70 inch
Qty：960 pcs/ 48 ctn
Total Weight: 1088 LBS
Lumens
- 1218 Lm
Watts
- 15 w
CRI
- 90 CRI
CCT
- Field Selectable CCT
- 2700K
- 3000K
- 3500K
- 4000K
- 5000K
Color / Finish
- White
Controls Options
- Motion Sensor
Dimming Protocol
- Triac (Leading Edge)
Lamp Life
- 50000 hrs
Lamp Source
- LED
Listings
- UL
Ratings & Compliance
- Damp
- Energy Star
- Title 24
Special Programs
- Quick Ship
Voltage
- 120 V
Warranty
- 10 yr
