LL-REM
LED Recessed Emergency Unit
Ultra-bright, energy efficient, long-life white LED lamp heads. 1.0 watt (1 LED x 1.0 watt) per head. Unique all-inclusive lamp, reflector, and lens assembly. Adjustable LED lamp heads provide up to 50-ft center to-center spacing with a 3-ft path of egress at 12-ft mounting height.
Resources
Injection-molded, engineering grade, 5VA flame retardant, thermoplastic oval and rectangle trim plates in white or black finish included
Dual 120/277 voltage
Unique bi-color LED indicator light alerts occupant on battery condition (Green-normal, Red-check battery)
Charge rate/power “ON” LED indicator light and push to-test switch for mandated code compliance testing
4.8V long-life, maintenance-free, rechargeable nickel metal hydride battery
Internal solid-state transfer switch automatically connects the internal battery to LED lamp heads for minimum 90- minute emergency illumination
Fully automatic solid-state, two rate charger initiates battery charging to recharge a discharged battery in 24 hours
Unique bi-color LED indicator light alerts occupant on battery condition (Green-normal, Red-check battery)
Charge rate/power “ON” LED indicator light and push to-test switch for mandated code compliance testing
4.8V long-life, maintenance-free, rechargeable nickel metal hydride battery
Internal solid-state transfer switch automatically connects the internal battery to LED lamp heads for minimum 90- minute emergency illumination
Fully automatic solid-state, two rate charger initiates battery charging to recharge a discharged battery in 24 hours
LED Recessed emergency lighting
Lumens
- 2 Lm
- 10 Lm
- 20 Lm
- 833 Lm
- 2023 Lm
Color / Finish
- Black
- White
Emergency Type
- Emergency Lighting
Lamp Source
- LED
Listings
- UL
Ratings & Compliance
- Damp
- NFPA 101
Special Programs
- Quick Ship
Warranty
- 7 yr
