LL-BLPECO (G2)
LL-BLPECO-22.jpegLL-BLPECO (G2)
Back Lit Panel Econolume Series Generation 2
The LITELUMEā¢ LED Back Lit Panel (G2) (LL-BLPECO) Econolume Series Generation 2 is a recessed, surface or suspended mounted luminaire designed for retrofit or new construction.
This architectural fixture adopts the latest in optical and LED technology providing an evenly pleasant illuminance. Featuring Selectable Power 3 level lumen output and Selectable Color Temperature, allowing for customized energy savings and comfortability. Controls ready.
Applications: Offices, hallways, multipurpose rooms, conference rooms, super markets, schools, stores and many other applications.
This architectural fixture adopts the latest in optical and LED technology providing an evenly pleasant illuminance. Featuring Selectable Power 3 level lumen output and Selectable Color Temperature, allowing for customized energy savings and comfortability. Controls ready.
Applications: Offices, hallways, multipurpose rooms, conference rooms, super markets, schools, stores and many other applications.
Resources
Premium Construction
Back Lit
Back Lit
Energy efficient: save up to 80% in energy costs
High lumen 130 LPW
LED Type SMD2835
PF .98
CRI 80
THD <20%
Driver Efficiency ļ¼90%
Operating Temperature -4Ā°F~122Ā°F
IC Rating Type IC
Damp Rated
Mercury-free
Instant-on light
60,000 hours at 70% lumen maintenance rated life
Compatible with most Lutron and Leviton dimmers
12Vdc auxiliary dimming
0-10V Continuous Dimming
Emergency Battery Backup
EMLY15/EMLY15-F
Tbar Mounting Kit For Emergency Battery Back Up
LL-TBAR
High lumen 130 LPW
LED Type SMD2835
PF .98
CRI 80
THD <20%
Driver Efficiency ļ¼90%
Operating Temperature -4Ā°F~122Ā°F
IC Rating Type IC
Damp Rated
Mercury-free
Instant-on light
60,000 hours at 70% lumen maintenance rated life
Compatible with most Lutron and Leviton dimmers
12Vdc auxiliary dimming
0-10V Continuous Dimming
Emergency Battery Backup
EMLY15/EMLY15-F
Tbar Mounting Kit For Emergency Battery Back Up
LL-TBAR
QuickShip Ordering Information
LL-BLPECO-14-4L-UNV-SCT-SP
LL-BLPECO-22--4L-UNV-SCT-SP
LL-BLPECO-24--6L-UNV-SCT-SP
Packageļ¼LL-BLPECO-14-4L-UNV-SCT-SP
Package Size: 49.2x6.2x13.7 inch
Weight: 22.44 LBS (4 PCS)
Pallet size: 42x48x80 inch
Qtyļ¼144 pcs / 36 ctn
Total Weight: 838 LBS
Factory Default Parameters:
Power: 30W
CCTļ¼4000K
Packageļ¼LL-BLPECO-22--4L-UNV-SCT-SP
Weight: 22.44 LBS (4 PCS)
Pallet size: 42x48x80 inch
Qtyļ¼144 pcs / 36 ctn
Total Weight: 838 LBS
Factory Default Parameters:
Power: 30W
CCTļ¼4000K
Packageļ¼LL-BLPECO-22--4L-UNV-SCT-SP
Package Size: 25.2x6.2x25.6 inch
Weight: 23.12 LBS (4 PCS)
Pallet size: 42x48x70 inch
Qtyļ¼144 pcs / 36 ctn
Total Weight: 870 LBS
Factory Default Parameters:
Power: 30W
CCTļ¼4000K
Packageļ¼
Weight: 23.12 LBS (4 PCS)
Pallet size: 42x48x70 inch
Qtyļ¼144 pcs / 36 ctn
Total Weight: 870 LBS
Factory Default Parameters:
Power: 30W
CCTļ¼4000K
Packageļ¼
LL-BLPECO-24--6L-UNV-SCT-SP
Package Size: 50x8.8x25.9 inch
Weight: 36.88 LBS (4 PCS)
Pallet size: 42x48x80 inch
Qtyļ¼72 pcs / 18 ctn
Total Weight: 694 LBS
Factory Default Parameters:
Power: 46W
CCTļ¼4000K
Weight: 36.88 LBS (4 PCS)
Pallet size: 42x48x80 inch
Qtyļ¼72 pcs / 18 ctn
Total Weight: 694 LBS
Factory Default Parameters:
Power: 46W
CCTļ¼4000K
Watts
- 20
- 25
- 30
- 35
- 40
- 46
Size
- 1x4
- 2x2
- 2x4
Availability
- In Stock
- Quick Ship
Beam Angle
- 113
CRI
- 80
CCT
- Field Selectable CCT
- 3500K
- 4000K
- 5000K
Color / Finish
- White
Dimming Protocol
- 0-10 V
- Bluetooth Wireless
Dimming Range
- 10-100%
Efficacy
- 130
Lamp Life
- 60000
Lamp Source
- LED
Listings
- UL
Mounting
- Recessed
- Surface
- Suspended
Emergency Options
- Emergency Battery Backup
Ratings & Compliance
- Damp
- IC Rated
- Interior
Shape
- Rectangular
- Square
Special Programs
- Quick Ship
- Stock
Voltage
- 120-277 V
Warranty
- 10 yr
