LL-WPCFC
DSC_7398-6-1.pngLL-WPCFC
LED Wallpack Curve - Full Cutoff
The LITELUME™ Wallpack Curve – Full Cutoff (LL-WPCFC) is a Dark Sky compliant LED fixture with a durable polycarbonate optical lens. Applications: Entryways, Tunnels, and Walkways, Exterior Wall Lighting, Building Entrances, Pedestrian Walkways, Multi-use Facilities, Industrial Facilities, Parking Lots, Storage Facilities, Education, Multi-Family, Retail, Office.
Resources
Die-cast Aluminum
Protective powder Coat
Polycarbonate lens
Protective powder Coat
Polycarbonate lens
Premium LED's
Ultra efficient driver
PF .90
CRI 80
THD <20%
Standard: 0-10v continuous 12Vdc auxiliary dimming
Field Selectable Lumens 4,116 to 9,800 lm
Field Selectable CCT
BUG ( Back, Up, Glare ) Rating
28W SETTING B1-U0-G3
42W SETTING B1-U0-G3
56W SETTING B1-U0-G3
70W SETTING B1-U0-G3
Ultra efficient driver
PF .90
CRI 80
THD <20%
Standard: 0-10v continuous 12Vdc auxiliary dimming
Field Selectable Lumens 4,116 to 9,800 lm
Field Selectable CCT
BUG ( Back, Up, Glare ) Rating
28W SETTING B1-U0-G3
42W SETTING B1-U0-G3
56W SETTING B1-U0-G3
70W SETTING B1-U0-G3
QuickShip Ordering Information
LL-WPCFC-[28][42][56][70]-3CCT-UNV-BZ-PC
Package:
Packing size：14.57x9.06x5.51 inch
Weight：7.23 LBS
Pallet size: 42x48x68 inch Qty：120 pcs
Total Weight: 9110 LBS
LED Wall Pack Lights
LED Dark Sky Outdoor Wall Lights
LED Full Cutoff Wall Packs
LED Wall Pack Lights
LED Dark Sky Outdoor Wall Lights
LED Full Cutoff Wall Packs
LL-WPCFC-[28][42][56][70]-3CCT-UNV-BZ-PC
Package:
Packing size：14.57x9.06x5.51 inch
Weight：7.23 LBS
Pallet size: 42x48x68 inch Qty：120 pcs
Total Weight: 9110 LBS
LED Wall Pack Lights
LED Dark Sky Outdoor Wall Lights
LED Full Cutoff Wall Packs
LED Wall Pack Lights
LED Dark Sky Outdoor Wall Lights
LED Full Cutoff Wall Packs
Lumens
- 4116 Lm
- 9800 Lm
Watts
- 28 w
- 42 w
- 56 w
- 70 w
CRI
- 80 CRI
CCT
- Field Selectable CCT
- 3000K
- 4000K
- 5000K
Color / Finish
- Bronze
Controls Options
- Photocell
Dimming Protocol
- 0-10 V
Efficacy
- 140 lm/w
Lamp Life
- 100000 hrs
Lamp Source
- LED
Listings
- UL
Materials
- Die-Cast Aluminum
Ratings & Compliance
- DarkSky Approved
- Wet
Special Programs
- Quick Ship
Voltage
- 120-277 V
Warranty
- 10 yr
