LL–RPDLL–RPD
LED Round Puff Drum
The LITELUME™ LED Round Puff Drum (LL–RPD) luminaire incorporates a low profile design. Features a die-formed cold rolled steel housing in white finish with a high transmission acrylic lens for a soft appearance. Offering 2 different sizes and wattages with multiple color temperature options, high power factor and low THD. Select models come in MCT (multiple color temperature 3000k/35000k/4000k) Applications: commercial, residential, hospitality and entertainment.
Resources
Lumens
- 1600 Lm
- 2560 Lm
- 3280 Lm
Watts
- 17 w
- 24 w
- 35 w
CRI
- 80 CRI
- 90 CRI
CCT
- Field Selectable CCT
- 3000K
- 3500K
- 4000K
Color / Finish
- White
Dimming Protocol
- 0-10 V
- Triac
Dimming Range
- 10%
Lamp Life
- 50000 hrs
Lamp Source
- LED
Listings
- ETL
Emergency Options
- Integral EM Battery
Ratings & Compliance
- Damp
- JA8
Special Programs
- Quick Ship
Voltage
- 120 V
- 120-277 V
- UNV
Warranty
- 10 yr
