LL-PTFR

Led Post Top Flat Round

The LITELUME™ Post Top Flat Round Luminaire (LL-PTFR) combines style, performance and adjustability. Featuring a die-cast aluminum housing with outstanding corrosion protection, and secondary UV resistant polycarbonate optics. The PTFR provides an aesthetically pleasing addition to any walkway, park, downtown corridor or parking lot with its steady well-defined construction. The highly functioning optics and adjustability provide maximum distribution to make the PTFR a premier choice for outdoor area lighting.
Specification Sheet

Resources

Specsheets


Photometry


Lumens

  • 4200 Lm
  • 7000 Lm
  • 8400 Lm
  • 11200 Lm
  • 14000 Lm
  • 16800 Lm
  • 21000 Lm

Watts

  • 30 w
  • 50 w
  • 60 w
  • 80 w
  • 100 w
  • 120 w
  • 150 w

CRI

  • 80 CRI

CCT

  • Field Selectable CCT
  • 3000K
  • 4000K
  • 5000K

Color / Finish

  • Bronze

Controls Options

  • Motion Sensor
  • Photocell

Dimming Protocol

  • 0-10 V

Distribution

  • Type V

Lamp Life

  • 74000 hrs

Lamp Source

  • LED

Listings

  • UL

Materials

  • Die-Cast Aluminum
  • Polycarbonate

Mounting

  • Integral Slip Fitter

Ratings & Compliance

  • DLC Premium
  • IP65
  • Title 24
  • Wet

Voltage

  • 120-277 V
  • 208-480 V
  • UNV

Warranty

  • 10 yr
