LED Post Top Flat Round
The LITELUME™ Post Top Flat Round Luminaire (LL-PTFR) combines style, performance and adjustability. Featuring a die-cast aluminum housing with outstanding corrosion protection, and secondary UV resistant polycarbonate optics. The PTFR provides an aesthetically pleasing addition to any walkway, park, downtown corridor or parking lot with its steady well-defined construction. The highly functioning optics and adjustability provide maximum distribution to make the PTFR a premier choice for outdoor area lighting.
Resources
QuickShip Ordering Information
LL-PTFR-[40][50][60]-3CCT-UNV-T5-BZ
LL-PTFR-[40][50][60]-3CCT-UNV-T5-BK
LL-PTFR-[60][80][100]-3CCT-UNV-T5-BZ
LL-PTFR-[60][80][100]-3CCT-UNV-T5-BK
LL-PTFR-[120][135][150]-3CCT-UNV-T5-BZ
LL-PTFR-[120][135][150]-3CCT-UNV-T5-BK
LL-PTFR-[40][50][60]-3CCT-UNV-T5-BZ
LL-PTFR-[40][50][60]-3CCT-UNV-T5-BK
LL-PTFR-[60][80][100]-3CCT-UNV-T5-BZ
LL-PTFR-[60][80][100]-3CCT-UNV-T5-BK
LL-PTFR-[120][135][150]-3CCT-UNV-T5-BZ
LL-PTFR-[120][135][150]-3CCT-UNV-T5-BK
Lumens
- 4200
- 7000
- 8400
- 11200
- 14000
- 16800
- 21000
Watts
- 30
- 50
- 60
- 80
- 100
- 120
- 150
CRI
- 80
CCT
- Field Selectable CCT
- 3000K
- 4000K
- 5000K
Color / Finish
- Bronze
Controls Options
- Motion Sensor
- Photocell
Dimming Protocol
- 0-10 V
Distribution
- Type V
Lamp Life
- 74000
Lamp Source
- LED
Listings
- UL
Materials
- Die-Cast Aluminum
- Polycarbonate
Mounting
- Integral Slip Fitter
Ratings & Compliance
- DLC
- DLC Premium
- IP65
- Title 24
- Wet
Special Programs
- Quick Ship
Voltage
- 120-277 V
- 208-480 V
- UNV
Warranty
- 10
