LL-VRSMLPLL-VRSMLP
LED Vandal Resistant Square Medium Low Profile
The LITELUMEā¢ Vandal Resistant Square Medium Low Profile (LL-VRSMLP) Surface Mount luminaire is available with an optical distribution designed specifically to replace HID lighting systems up to 100w MH or HPS.
Heavy Duty Max Security 10 gauge Die-cast Aluminum Housing
Polycarbonate VandalResistant Lens 1/2" thick Max Security
Typical lighting applications include retail centers, industrial parks, schools and universities, public transit and airports, office buildings and medical facilities. Mounting heights of 8 to 14 feet can be used based on light level and uniformity requirements.
Heavy Duty Max Security 10 gauge Die-cast Aluminum Housing
Polycarbonate VandalResistant Lens 1/2" thick Max Security
Typical lighting applications include retail centers, industrial parks, schools and universities, public transit and airports, office buildings and medical facilities. Mounting heights of 8 to 14 feet can be used based on light level and uniformity requirements.
Resources
Heavy Duty Die Cast Aluminum Housing, 1ā2 Ģ Coin Plugs with O-rings for Conduit & Photocell on Two Sides & Back
Nickel-Plated Stainless Steel Hardware
Mount Directly Over a 4 Ģ Recessed Outlet Box, or Use 1ā2 Ģ Surface Conduit
Corrosion-resistant Architectural Powder coat Finish Over a Chromate Conversion Coating
Sealed LED Compartment with Aluminum Boards
Opal UV-Stabilized Polycarbonate Vandal-Resistant Lens with soft LED
Nickel-Plated Stainless Steel Hardware
Mount Directly Over a 4 Ģ Recessed Outlet Box, or Use 1ā2 Ģ Surface Conduit
Corrosion-resistant Architectural Powder coat Finish Over a Chromate Conversion Coating
Sealed LED Compartment with Aluminum Boards
Opal UV-Stabilized Polycarbonate Vandal-Resistant Lens with soft LED
Premium LED's
Ultra efficient driver
PF .90
CRI 80
THD <20%
Dimming Range of 100% to 10%
Ultra efficient driver
PF .90
CRI 80
THD <20%
Dimming Range of 100% to 10%
QuickShip Ordering Information
LL-VRSMLP-23-40-UNV-BZ
LL-VRSMLP-23-50-UNV-BZ
LED Vandal Resistant Lights
LL-VRSMLP-23-40-UNV-BZ
LL-VRSMLP-23-50-UNV-BZ
LED Vandal Resistant Lights
Lumens
- 2774 Lm
- 2890 Lm
Watts
- 23 w
- 100 w
CCT
- 4000K
- 5000K
Color / Finish
- Bronze
Dimming Protocol
- 0-10 V
Lamp Life
- 169000 hrs
Lamp Source
- LED
Listings
- CSA
- UL
Materials
- Die-Cast Aluminum
- Polycarbonate
Emergency Options
- Emergency Battery Backup
Ratings & Compliance
- ADA
- Buy American Act (BAA)
- IP66
- Wet
Special Programs
- Quick Ship
Voltage
- 120-277 V
- 347-480 V
- UNV
Warranty
- 10 yr
