LL-RW

Roadway

The LITELUMEā„¢ Roadway (LL-RW) Draws attention with a heavy duty die-cast aluminum housing, outstanding corrosion protection, uncompromising optical performance and un-matched versatility for a wide variety of area and roadway applications. Featuring a single latch tool-less entry, terminal block power set up, industry leading surge protection options, superior lumen maintenance with a robust yet economical design. Applications: Roadways, Multi-family, Community and general site illumination.
Specification Sheet

Resources

QuickShip Ordering Information

  • LL-RW-70-40-UNV-T3-GY-PC
  • LL-RW-105-40-UNV-T3-GY-PCĀ
  • LL-RW-150-40-UNV-T3-GY-TLPCĀ
  • LL-RW-150-50-UNV-T3-GY-TLPC

Lumens

  • 9900 Lm
  • 14600 Lm
  • 20000 Lm

Watts

  • 70 w
  • 105 w
  • 150 w

CRI

  • 80 CRI

CCT

  • Field Selectable CCT
  • 3000K
  • 4000K
  • 5000K

Color / Finish

  • Black
  • Bronze
  • Grey
  • White

Controls Options

  • Motion Sensor
  • Photocell

Dimming Protocol

  • 1-10 V

Distribution

  • Type II
  • Type III

Efficacy

  • 135 lm/w
  • 141 lm/w

Lamp Life

  • 100000 hrs

Lamp Source

  • LED

Listings

  • UL

Materials

  • Die-Cast Aluminum
  • Polycarbonate

Ratings & Compliance

  • Buy American Act (BAA)
  • IP66
  • TAA
  • Wet

Special Programs

  • Quick Ship

Voltage

  • 120-277 V
  • 480 V
  • UNV

Warranty

  • 10 yr
