LL-ARCL

LED Architectural Round Canopy Large

The Litelume Architectural Round Canopy Large (LL-ARCL) is available in Type III or V distributions with two lens options designed to replace HID lighting systems up to 1000w MH or HPS. Typical area lighting applications include retail centers, industrial parks, schools and universities, public transport and airports, office buildings and medical facilities. Mounting heights of 12 to 30 feet can be used based on light level and uniformity requirements.
Specification Sheet

Resources

Specsheets


Lumens

  • 7661 Lm
  • 7959 Lm
  • 10693 Lm
  • 10896 Lm
  • 12958 Lm
  • 13483 Lm
  • 17880 Lm
  • 18818 Lm
  • 19174 Lm
  • 31259 Lm
  • 32477 Lm

Watts

  • 100 w
  • 176 w
  • 276 w
  • 1000 w

CRI

  • 80 CRI

CCT

  • 3000K
  • 4000K
  • 5000K

Controls Options

  • Motion Sensor

Distribution

  • Type III
  • Type V

Lamp Source

  • LED

Listings

  • CSA

Materials

  • Die-Cast Aluminum
  • Polycarbonate

Ratings & Compliance

  • ADA
  • Buy American Act (BAA)
  • IP66
  • Wet

Voltage

  • 120-277 V
  • UNV

Warranty

  • 10 yr
