LL-BCP
Boxy Canopy Premium
The LITELUME⢠LED Boxy Canopy Premium (LL-BCP) is engineered with cutting edge craftsmanship and technology. Rugged anti corrosion die cast aluminum housing. Featuring a low glare lense with parking garage photometry, precision illumination, ultimate comfortability and security.
Plug and Play controls ready, selectable wattage and CCT is standard, making this fixture ideal for parking garages, storage areas, walkways and low or high security areas.Ā
Plug and Play controls ready, selectable wattage and CCT is standard, making this fixture ideal for parking garages, storage areas, walkways and low or high security areas.Ā
Resources
Heavy duty rugged die cast aluminum
Corrosion-resistant powder coat
Parking Garage photometry
Precision-engineered anti-glare optical lens provides comfortable illumination
External quick-mount plate for standard J-BOX mounting
Compatible with 3/4" pendantĀ
Includes 1/2" knock-out holes reserved on all four sides
Suitable for surface conduit wiring installation
Corrosion-resistant powder coat
Parking Garage photometry
Precision-engineered anti-glare optical lens provides comfortable illumination
External quick-mount plate for standard J-BOX mounting
Compatible with 3/4" pendantĀ
Includes 1/2" knock-out holes reserved on all four sides
Suitable for surface conduit wiring installation
Premium LED's
Ultra efficient driver
PF .90
CRI 80
THD <20%
Ultra efficient driver
PF .90
CRI 80
THD <20%
QuickShip Ordering Information
LL-BCP-[16][24][32][40]-3CCT-UNV-BZ
LL-BCP-[24][36][48][60]-3CCT-UNV-BZ
LL-BCP-[28][42][56][70]-3CCT-UNV-BZ
LL-BCP-[16][24][32][40]-3CCT-UNV-BZ
LL-BCP-[24][36][48][60]-3CCT-UNV-BZ
LL-BCP-[28][42][56][70]-3CCT-UNV-BZ
Lumens
- 2700 Lm
- 3900 Lm
- 4100 Lm
- 4600 Lm
- 5100 Lm
- 6100 Lm
- 6200 Lm
- 6700 Lm
- 7900 Lm
- 8700 Lm
- 9400 Lm
- 10500 Lm
Watts
- 16 w
- 24 w
- 28 w
- 32 w
- 36 w
- 40 w
- 42 w
- 48 w
- 56 w
- 60 w
- 70 w
Beam Angle
- 270
CRI
- 80 CRI
CCT
- Field Selectable CCT
- 3000K
- 4000K
- 5000K
Color / Finish
- Black
- Bronze
- Custom
- Gray
- White
Dimming Protocol
- 1-10 V
Lamp Life
- 100000 hrs
Lamp Source
- LED
Listings
- UL
Materials
- Die-Cast Aluminum
- Polycarbonate
Emergency Options
- Emergency Battery Backup
Ratings & Compliance
- Buy American Act (BAA)
- DLC
- TAA
- Wet
Shape
- Square
Special Programs
- Quick Ship
Voltage
- 120-277 V
Warranty
- 10 yr
