LL-CYL-L
LL-CYL-EM-R(2).jpegLL-CYL-L
Cylinder Large
The LITELUME™ LED Cylinder Large (LL-CYL-L) is a specification grade field adjustable Downlight luminaire designed for retrofit or new construction. Available in 8”, and 10” diameters. Featuring 3 level lumen output and 3 color adjustable CCT, allowing for customized energy savings and comfortability.
Applications include hospitals, schools, restaurants, offices, hallways, conference rooms, bathrooms and many other commercial, residential & Hospitality areas.
Resources
Mounting:
Standard: Direct Mount, Ceiling Mount , or Suspended with connectable 24” or 48” Rigid Stem Mounts
Standard: Direct Mount, Ceiling Mount , or Suspended with connectable 24” or 48” Rigid Stem Mounts
QuickShip Ordering Information
LL-CYL-L-8-SC-[30][45][55]-3CCT-UNV-75D-BK
LL-CYL-L-10-SC-[75][95][105]-3CCT-UNV-75D-BK
LL-CYL-L-8-SC-[30][45][55]-3CCT-UNV-75D-WH
LL-CYL-L-10-SC-[75][95][105]-3CCT-UNV-75D-WH
LED Cylinder Downlight
LED Architectural Pendant
LL-CYL-L-8-SC-[30][45][55]-3CCT-UNV-75D-BK
LL-CYL-L-10-SC-[75][95][105]-3CCT-UNV-75D-BK
LL-CYL-L-8-SC-[30][45][55]-3CCT-UNV-75D-WH
LL-CYL-L-10-SC-[75][95][105]-3CCT-UNV-75D-WH
LED Cylinder Downlight
LED Architectural Pendant
Lumens
- 4289
- 6434
- 7864
- 10562
- 13379
- 14788
Watts
- 30
- 45
- 55
- 75
- 95
- 105
Availability
- In Stock
- Quick Ship
Beam Angle
- 45
- 75
CRI
- 80
CCT
- Field Selectable CCT
- 3000K
- 4000K
- 5000K
Color / Finish
- Black
- Grey
- White
Dimming Protocol
- 0-10 V
Lamp Life
- 100000
Lamp Source
- LED
Listings
- UL
Materials
- Die-Cast Aluminum
- Glass
Mounting
- Pendant
Ratings & Compliance
- Wet
Voltage
- 120-277 V
Warranty
- 10
