LL-RCSR

LED Recessed Canopy Soffit Replacement

The LITELUME™ Recessed Canopy Soffit Replacement (LL-RCSR) is available with an optical distribution designed to replace HID lighting systems up to 250w MH or HPS. The low profile housing is designed to replace existing recessed canopy lights up to 12? round or square, and can be used in new construction.

Typical applications include covered entryways and soffits in retail centers, schools and universities, office buildings and medical facilities. Mounting heights of 12 to 16 feet can be used based on light level and uniformity requirements.

Specification Sheet

Resources Inspiration Similar Products Collections

Resources

Specsheets

LL-RCSR

Install Guides

LL-RCSR installation-guide .pdf

Die Cast Aluminum Driver Compartment with Formed Steel Plate.
Corrosion-resistant Architectural Powder coat Finish Over a Chromate Conversion Coating
Molded Polycarbonate Optical Lens
Soft LED
Recessed Mount

Premium LED's
Ultra efficient driver
PF .90
CRI 80
THD <20%
Internal Surge Protection 6kV
0-10V Dimming Standard
Dimming Range of 100% to 10%

QuickShip Ordering Information
LL-RCSR-30-30-UNV-WH
LL-RCSR-30-40-UNV-WH
LL-RCSR-37-40-UNV-WH
LL-RCSR-48-40-UNV-WH
LL-RCSR-48-50-UNV-WH
LL-RCSR-65-40-UNV-WH
