LL-MODGR6LL-MODGR6
LED 6” Trim Recessed Module Gimbal Downlight
The LITELUME™ LL-MODGR6 Trim Recessed Module Gimbal Downlight delivers sleek performance and versatility for modern spaces. Available in 6" with 5 CCT field selectable color temperatures ranging from 2700K to 5000K. Aesthetic appeal and elegant illumination. Pairs with our LED dedicated 4" can with quick connector, ideal for new construction, or use the screw-in adapter to retrofit any 6" incandescent can for a perfect energy upgrade.
Resources
Premium Powder Coat
Aluminum White Housing
Polycarbonate diffuser
Gimbal, max. tilts angle 60° and swivels a full 360°
Aluminum White Housing
Polycarbonate diffuser
Gimbal, max. tilts angle 60° and swivels a full 360°
PF > 0.90.
THD < 20%
CRI 90
Triac Dimming @ 120v
Surge Protection = 1kV
Operating Temperature -4°F to 113°F
cETLus listed for damp locations
Energy Star certified
Complies with FCC part 15, class B
Complies with Title 24
Type IC
LUTRON COMPATIBLE DIMMERS AND CONTROLS
TG-600PR-WH
SLV-600P-AL
DVCL-153P
S-600PR-WH
DV-600PR-WH
MSCL-OP153M
CTCL-153PDH-WH
SCL-153PH-WH
PD-6WCL
TGCL-153PH-LA
GT-600P
MACL-153M//MA-R
LEVITON COMPATIBLE DIMMERS AND CONTROLS
6672
6674
IPL06
RNL06
DSL06
THD < 20%
CRI 90
Triac Dimming @ 120v
Surge Protection = 1kV
Operating Temperature -4°F to 113°F
cETLus listed for damp locations
Energy Star certified
Complies with FCC part 15, class B
Complies with Title 24
Type IC
LUTRON COMPATIBLE DIMMERS AND CONTROLS
TG-600PR-WH
SLV-600P-AL
DVCL-153P
S-600PR-WH
DV-600PR-WH
MSCL-OP153M
CTCL-153PDH-WH
SCL-153PH-WH
PD-6WCL
TGCL-153PH-LA
GT-600P
MACL-153M//MA-R
LEVITON COMPATIBLE DIMMERS AND CONTROLS
6672
6674
IPL06
RNL06
DSL06
QuickShip Ordering Information
LL-MODGR6-10L-KFS
LL-MODGR6-10L-KFS
Lumens
- 1000 Lm
Watts
- 14 w
Weight
- .66 lbs
Availability
- In Stock
- Quick Ship
CRI
- 90 CRI
CCT
- Field Selectable CCT
- 2700K
- 3000K
- 3500K
- 4000K
- 4500K
Color / Finish
- White
Dimensions
- H: 2.8 In. L: 7.39 In. W: 7.38 In.
Dimming Protocol
- Triac (Leading Edge)
Dimming Range
- 1%
Efficacy
- 71 lm/w
Installation Type
- New Construction
- Retrofit & Remodel
Lamp Base
- E26
Lamp Life
- 174000 hrs
Lamp Source
- LED
Listings
- ETL
Materials
- Aluminum
- Polycarbonate
Ratings & Compliance
- Damp
- Energy Star
- FCC
- IC Rated
- JA8
- Title 24
Shape
- Round
Special Programs
- Quick Ship
- Stock
Trim Finish
- White
Trim Type
- Gimbal
Voltage
- 120 V
Warranty
- 10 yr
