Die-cast Aluminum Housing
Powder Coat Finish Over a Chromate Conversion Coating
Clear Tempered Glass
Stainless steel 304 Hardware
3G Vibration Rated
Top Opening 3/4 NPT Standard ( Optional M25 )
Side Openings 3/4 NPT Standard ( Optional M20, M25, 1/2 NPT )
Ceiling, Wall Mount with standard U-Bracket, optional Pendant or Stanchion Mount

Premium LED's
Premium Meanwell Driver
PF .95
CRI 80
THD <20%
High Efficacy up to 140 lm/W
Standard 0-10v Dimming
NEMA 4X
IP66
IK08
UL1598 and UL1598A
UL844
CSA C22.2 No.137/No.250.0
Class l, Division 2, Groups A, B, C, D
Class 2, Division 1, Groups E, F, G
Class 2, Division 2, Groups F, G
Class 3
Marine and Wet Locations
DNV
ABS

QuickShip Ordering Information

Built to order Information
8 Weeks

Package: LL-SBHL-S
Package Size: 14.37x10.63x12.01 inch
Weight: 11.68 LBS (1 PCS)

Package: LL-SBHL-M
Package Size: 17.72x13.39x14.57 inch
Weight: 20.94 LBS (1 PCS)

Package: LL-SBHL-L
Package Size: 18.50x14.57x11.81 inch
Weight: 25.02 LBS (1 PCS)

Package: LL-SBHL-XL
Package Size: 19.57x18.31x13.78 inch
Weight: 40.90 LBS (1 PCS)

LITELUME new LED lighting fixtures in Harsh & Hazardous environments Class 1 & Class 2, when delivered in new condition in its original packaging and installed properly by a licensed electrician, will be free of defects in workmanship for a period of TEN (10) YEARS from the date of original purchase. Litelume warrants these fixtures for (10) YEARS or 50,000 hours of which comes first. The LED driver and other internal components are warranted for (5) YEARS or 50,000 hours of which comes first.

LED Hazardous Lights
