LL-ALSL (G8)
Screen Shot 2023-12-12 at 1.38.44 PM.png
LL-ALSL-140-2.jpgLL-ALSL (G8)
LED Area Light Slim Series Generation 8
The LITELUMEā¢ Area Light Slim Series Luminaire (LL-ALSL) combines style, performance and competitiveness. Featuring a rugged one piece die-cast aluminum housing with outstanding corrosion protection, and secondary UV resistant polycarbonate optics. Compact in design low profile 3G vibration rated. Wattage and CCT Selectable with many accessories to customize.
The ALSL provides an aesthetically pleasing addition to any roadway or parking lot with its steady well defined construction. The highly functioning optics provide maximum lumen output and light distribution to make the ALSL the premier outdoor area light.
The ALSL provides an aesthetically pleasing addition to any roadway or parking lot with its steady well defined construction. The highly functioning optics provide maximum lumen output and light distribution to make the ALSL the premier outdoor area light.
Resources
Photometry
- LL-ALSL-[40][60][80][100]-3CCT-UNV-T2.zip
- LL-ALSL-[60][90][120][140]-3CCT-UNV-T2.zip
- LL-ALSL-[72][108][144][180]-3CCT-UNV-T2.zip
- LL-ALSL-[100][150][200][250]-3CCT-UNV-T2.zip
- LL-ALSL-[120][180][240][300]-3CCT-UNV-T2.zip
- LL-ALSL-[300][320][360][400]-2CCT-UNV-T2-.zip
- LL-ALSL-[40][60][80][100]-3CCT-UNV-T3.zip
- LL-ALSL-[60][90][120][140]-3CCT-UNV-T3.zip
- LL-ALSL-[72][108][144][180]-3CCT-UNV-T3.zip
- LL-ALSL-[100][150][200][250]-3CCT-UNV-T3.zip
- LL-ALSL-[120][180][240][300]-3CCT-UNV-T3.zip
- LL-ALSL-[300][320][360][400]-2CCT-UNV-T3.zip
- LL-ALSL-[40][60][80][100]-3CCT-UNV-T4.zip
- LL-ALSL-[60][90][120][140]-3CCT-UNV-T4.zip
- LL-ALSL-[72][108][144][180]-3CCT-UNV-T4.zip
- LL-ALSL-[100][150][200][250]-3CCT-UNV-T4.zip
- LL-ALSL-[120][180][240][300]-3CCT-UNV-T4-.zip
- LL-ALSL-[300][320][360][400]-2CCT-UNV-T4-.zip
- LL-ALSL-[40][60][80][100]-3CCT-UNV-T5.zip
- LL-ALSL-[60][90][120][140]-3CCT-UNV-T5.zip
- LL-ALSL-140-3K-T3- EGSALSL.ies
Durable one-piece die-cast aluminum housingĀ
Low profile, 3G vibration rated compact design
Housing is completely sealed against moisture and environmental contaminants
Polycarbonate lens
Protective Powder Coat
Standard Audio Jack Controls Ready
Low profile, 3G vibration rated compact design
Housing is completely sealed against moisture and environmental contaminants
Polycarbonate lens
Protective Powder Coat
Standard Audio Jack Controls Ready
Premium LED's
Ultra efficient driver
Universal 120-277V AC or 480V AC input voltage.
Standard 10KV(@120-277V) or 20KV(@277-480V) surge protection
PF .90
CRI 80
THD <20%
Standard 0-10v dimming with 10 - 100% range
Field Selectable Power
Field Selectable Color Temperature 3000k, 4000k, and 5000k
Operating temperature -40 ĢC to 45 ĢC (-40 ĢF to 113 ĢF)
Estimated 100,000-hour LED lifespan based on IES LM-80 results and TM-21 calculations
Ultra efficient driver
Universal 120-277V AC or 480V AC input voltage.
Standard 10KV(@120-277V) or 20KV(@277-480V) surge protection
PF .90
CRI 80
THD <20%
Standard 0-10v dimming with 10 - 100% range
Field Selectable Power
Field Selectable Color Temperature 3000k, 4000k, and 5000k
Operating temperature -40 ĢC to 45 ĢC (-40 ĢF to 113 ĢF)
Estimated 100,000-hour LED lifespan based on IES LM-80 results and TM-21 calculations
QuickShip Ordering Information
LL-ALSL-[40][60][80][100]-3CCT-UNV-T3-BZ
LL-ALSL-[60][90][120][140]-3CCT-UNV-T3-BZ
LL-ALSL-[60][90][120][140]-3CCT-480-T3-BZ
LL-ALSL-[60][90][120][140]-3CCT-UNV-T3-BK*
LL-ALSL-[60][90][120][140]-3CCT-UNV-T3-WH*
LL-ALSL-[72][108][144][180]-3CCT-UNV-T3-BZ
LL-ALSL-[72][108][144][180]-3CCT-480-T3-BZ
LL-ALSL-[120][180][240][300]-3CCT-UNV-T3-BZ
LL-ALSL-[120][180][240][300]-3CCT-480-T3-BZ
LL-ALSL-[120][180][240][300]-3CCT-UNV-T3-BK*
LL-ALSL-[120][180][240][300]-3CCT-UNV-T3-WH*
LL-ALSL-[300][320][360][400]-2CCT-UNV-T3-BZ
LL-ALSL-[300][320][360][400]-2CCT-480-T3-BZ
*Please allow 2 - 3 weeks to paint the specified mounting bracket for black & white area lights
LED Area Light Generation 8
LL-ALSL-[60][90][120][140]-3CCT-480-T3-BZ
LL-ALSL-[60][90][120][140]-3CCT-UNV-T3-BK*
LL-ALSL-[60][90][120][140]-3CCT-UNV-T3-WH*
LL-ALSL-[72][108][144][180]-3CCT-UNV-T3-BZ
LL-ALSL-[72][108][144][180]-3CCT-480-T3-BZ
LL-ALSL-[120][180][240][300]-3CCT-UNV-T3-BZ
LL-ALSL-[120][180][240][300]-3CCT-480-T3-BZ
LL-ALSL-[120][180][240][300]-3CCT-UNV-T3-BK*
LL-ALSL-[120][180][240][300]-3CCT-UNV-T3-WH*
LL-ALSL-[300][320][360][400]-2CCT-UNV-T3-BZ
LL-ALSL-[300][320][360][400]-2CCT-480-T3-BZ
*Please allow 2 - 3 weeks to paint the specified mounting bracket for black & white area lights
LED Area Light Generation 8
Lumens
- 7000
- 10000
- 10600
- 12500
- 13000
- 15500
- 15800
- 17000
- 18000
- 20000
- 21500
- 22500
- 23000
- 24500
- 27000
- 30000
- 31000
- 37000
- 38500
- 45000
- 46500
- 50500
- 55500
- 60800
Watts
- 40
- 60
- 72
- 80
- 90
- 100
- 108
- 120
- 140
- 144
- 150
- 180
- 240
- 250
- 300
- 320
- 360
- 400
CRI
- 80
CCT
- Field Selectable CCT
- 3000K
- 4000K
- 5000K
Color / Finish
- Black
- Bronze
- Gray
- White
Controls Options
- Motion Sensor
- Occupancy Sensor
- Photocell
Dimming Protocol
- 0-10 V
Distribution
- Type II
- Type III
- Type IV
- Type V
Efficacy
- 150
Lamp Life
- 100000
Lamp Source
- LED
Listings
- UL
Materials
- Die-Cast Aluminum
- Polycarbonate
Mounting
- Slip Fitter
- Trunnion
- Wall
Ratings & Compliance
- Buy American Act (BAA)
- DLC
- DarkSky Approved
- IP66
- TAA
- Title 24
- Wet
Special Programs
- Quick Ship
Voltage
- 120-277 V
- 347-480 V
- UNV
Warranty
- 10 yr
